Family |
Cmin Range pF |
Cmax Range pF |
Max. Voltage V rms |
lenght* (mm) |
width (mm) |
hight (mm) |
Standard Feautures |
Options |
ATM  |
1.2 - 2.9 |
3.0 - 21.8 |
500 |
14 - 30 |
15 |
18 | non-magnetic ceramic insulators slotted shaft |
look bearing dual-stator |
APC  |
2.5 - 7.2 2.5 - 7.9 2.5 - 7.3 2.5 - 7.0 |
6.0 - 143.7 5.3 - 111.5 4.2 - 51.1 3.7 -29.2 |
500 600 700 1000 |
17 - 46 18 - 49 18 - 46 17 - 46 |
24 24 24 24 |
31 31 31 31 |
non magnetic mil-spec ceramic |
lock bearing insulated shaft slotted shaft mounting pillars |
APL  |
2.6 - 10.8 2.4 - 10.8 2.5 - 15.9 2.3 - 9.1 2.5 - 14.0 |
10.5 - 322.7 8.2 - 243.2 6.4 - 207.5 4.8 - 76.2 4.1 - 50.0 |
640 800 1070 1500 2000 |
17 - 46 17 - 49 16 - 76 19 - 50 20 - 76 |
36 36 36 36 36 |
35 35 35 35 35 |
non-magnetic high-quality ceramics |
lock bearing rear ceramic insulated and/or slotted shaft mounting pillars 180 degree rotor stop stator lugs |
N50  |
5.0 - 15.9 4.9 - 11.5 |
54.2 - 409.9 11.2 - 66.8 |
350 1200 |
31 |
35 |
34 |
ball bearings high pF unit volume 180 degree stop |
8:1 reduction drive trimmer caps dual stator cw or ccw rotation |
M73  |
6.0 - 36.2 8.0 - 39.2 7.0 - 38.7 6.7 - 38.7 5.6 - 30.0 5.0 - 39.0 |
23 - 1529 20 - 1099 12 - 523 11 - 403 10 - 277 8.5 - 228 |
1100 1550 2500 3100 3500 3700 |
33 - 200 33 - 230 34 - 240 35 - 290 35 - 290 36 - 300 |
66 66 66 66 66 66 |
66 66 66 66 66 66 |
ball bearings heavy ceramics thick plates |
non-magnetic high quality M73A dual stator drop-in replacement mounting configurations |
M90  |
10 - 36 10 - 34 10 - 32 |
16 - 440 14 - 200 13 - 100 |
5000 7500 10000 |
45 - 465 48 - 465 52 - 465 |
108 108 108 |
106 106 106 |
non-magnetic instrument bearings ultem insulators assembled in cleanroom |
high-amperage ARA contact dual stator insulated slotted flatted shaft |
M97  |
8 - 38 10 - 41 9 - 40 9 - 44 8 - 36 8 - 40 |
52 - 4000 45 - 2500 27 - 1690 23 - 935 20 - 680 16 - 440 |
1100 1550 2500 3500 4200 5000 |
45 - 230 45 - 250 45 - 360 45 - 465 45 - 465 45 - 465 |
98 98 98 98 98 98 |
100 100 100 100 100 100 |
non-magnetic instrument bearings ultem insulators strap contact high- amperage assembled in cleanroom |
high-amperage ARA contact dual stator insulated shaft slotted shaft flatted shaft |
