Grid assembly for the 5CX1500B and 3CX800A7 |
Winding of mesh filaments for the 3CX3000A7 and 4CX10,000D |
Winding of mesh filaments for the 3CX3000A7 and 4CX10,000D |
|
A few of Svetlana's Metal Ceramic tube assembly team |
Environmentally controlled storage cabinets keep tube parts clean and dust free |
Mesh filaments stored in dust-free cabinets ready for assembly |
|
3CX10,000A7 assembly of grid, filament, getters and base. Tooling assures proper alignment before welding |
Assembly of fins on large power tubes in the 3CX10,000 and 3CX15,000 series |
Furnace tanks apply intense heat for brazing tube parts into assemblies |
|
Quality control check of the 4CX1500A grid/filament assembly |
Vacuum pumping equipment for metal/ceramic power tubes |
Quality control room for assurance of welding integrity |
|
4CX350A tube testing |
Burning tetrodes in or "training" 4CX1600B |
Close up of previous picture showing individual 4CX1600B tetrodes with power applied |
|
Socket assembly quality inspection |
